KumoScale™ Software

- IMPORTANT NOTICE -

Thank you for interest in KumoScale™ software ("Product"). There is no plan for enhancement beyond Version 3.22 as the Product has transitioned to maintenance only, and no new evaluation or production licenses will be granted. If you have any questions, please contact us.

Disaggregated NVMe-oF™ Storage Management for Data Centers

KumoScale™ software implements the NVMe™ over Fabrics (NVMe-oF™). By which the product provides a fast, networked block storage service between initiator and target through high speed network connection.The software runs on storage node populated with NVMe™ SSD and realizes storage disaggregation. KumoScale software supports both RDMA and NVMe over TCP for network transport and that provides shared, clustered storage pool to enable logical split by NVMe namespace on a bunch of SSDs. Comparing to Direct Attached Storage(DAS), KumoScale volume management capability gives much flexibility to control big storage pool that consists of large individual SSDs.

Use Case
Function
V3.22 Highlight
Architecture
Platform Requirements
V3.22 User Manual
Documents
Inquiries
Press Release

Use Case

Typical application and use case

  • High performance storage service for cloud-native application
  • Persistent storage service for OpenStack™ and Kubernetes®
  • High speed block storage service for HPC applications and other scentific application
  • Backend storage for AI/ML/DL applications

KumoScale™ software should work with generally available NVMe-oF™ initiator software as well as standard based NVMe SSDs. Proprietary software driver or hardware are not necessary.

Function

Improve storage utilization and better flexibility to manage pooled fast NVMe™ SSD

Capacity and performance of latest PCIe® Gen 4 NVMe SSD is exploded than that of PCIe Gen 3 and are far more than a single compute node can consume. Sharing SSDs over different user applications and servers/VMs are an urgent need. Until NVMe-oF™ is introduced and widely spread, networked storage has been either slow or expensive, or both. It is no longer true with NVMe-oF™. KumoScale™ software increases storage utilization by sharing SSD, dividing shared SSD by NVMe name space and adds more flexibility to provision the right amount of capacity from the pool through the software at the performance of NVMe™ SSD.

An Introduction to PCIe® 4.0 performance with KIOXIA CM6 Series SSDs and KumoScale Software (PDF : 5MB) PDF will open in a new window.

Supports RDMA and NVMe over TCP protocol

KumoScale software supports RDMA and TCP transport protocol. If you seek faster and low latency storage service by KumoScale software, RoCEv2(RDMA over Converged Ethenet) should fit. On the other hand if you prefer network compatibility in existing data center network, TCP/IP could be used for KumoScale software. For network card validated with latest KumoScale software please refer to HCL(Hardware Compatibility List).

Adapting customer provisioning and telemetry architecture

  • For OpenStack®, KumoScale™ software provides OpenStack Cynder® driver supporting Wallaby release and beyond.
  • For Kubernetes® ,containerized applications are connected to KumoScale™ storage node by KumoScale Container Storage Interface (CSI) driver.
  • For baremetal environment, Ansible™ playbooks or other popular automation tools may be used for deployment automation and provisioning of storage to compute nodes.
  • For telemetry integration, KumoScale™ software provides interface to enable push/pull data exchange for existing telemetry (time series metrics) and logging (asynchronous events) infrastructure.

Data Protection and High Availability

Data Protection -Cross Domain Data Replication (CDDR)-
KumoScale™ software provides data protection via a technique called Cross Domain Data Replication (CDDR).  CDDR creates multiple replicas of a logical volume on top of pooled SSDs, and maps them to storage nodes located in different failure domains. The replication is based on initiator and replica can be placed across 2nd or 3rd KumoScale™ storage node. For replication KumoScale agent runs on initiator to check volume availability. Once the agent  detects volume falure whatever reasons, the volume is automatically reconnected to replicated volume on different storage node. After resilient volume comes back from the failure, all data is rebuild to fresh resilient volume automatically.

Delivering Next-Generation NVMe-oF™ Data Resilience in the Data Center (PDF : 810KB) PDF will open in a new window.

Ensure High Availability
KumoScale™ storage node supports L3 BGP (Border Gate Protocol) so that network path is automatically rerouted to available network path based on predefined optimal routing table when there is network connection issue.

V3.22 Highlight

Volume Migration:
Enhanced volume migration allows an administrator to migrate a volume across storage nodes without disruption for maintenance and utilization. Volumes remain online and continue to serve I/O during the process of moving the data to its new location. The operation is completely transparent to the applications using the volume, enhancing storage cluster resilience.

Cluster Manager CLI v2:
An enhanced Cluster Manager CLI extends the 3.21 CLI v1 to add operator-driven lifecycle automation capabilities available in the KumoScale™ control plane. The 3.22 Cluster Manager CLI now gives administrators full access to both cluster services management and storage provisioning functions via a single, intuitive CLI.

Flexible Volume Class:
A new flexible volume class allows data center infrastructure providers to start their tenants with a non-replicated volume and later upsell them to a resilient replicated volume. It allows data center infrastructure providers to deploy their tenants quickly and add appropriate resiliency in later phase.

KumoScale™ software version 3.22 also includes an improved online technical documentation, Ansible® refactoring for easier storage administrator script adaptation, and modifiable cluster VIP address.

Volume Migration:
Enhanced volume migration allows an administrator to migrate a volume across storage nodes without disruption for maintenance and utilization. Volumes remain online and continue to serve I/O during the process of moving the data to its new location. The operation is completely transparent to the applications using the volume, enhancing storage cluster resilience.

Cluster Manager CLI v2:
An enhanced Cluster Manager CLI extends the 3.21 CLI v1 to add operator-driven lifecycle automation capabilities available in the KumoScale™ control plane. The 3.22 Cluster Manager CLI now gives administrators full access to both cluster services management and storage provisioning functions via a single, intuitive CLI.

Flexible Volume Class:
A new flexible volume class allows data center infrastructure providers to start their tenants with a non-replicated volume and later upsell them to a resilient replicated volume. It allows data center infrastructure providers to deploy their tenants quickly and add appropriate resiliency in later phase.

KumoScale™ software version 3.22 also includes an improved online technical documentation, Ansible® refactoring for easier storage administrator script adaptation, and modifiable cluster VIP address.

Architecture

Data Center System Architecture

KumoScale™ architecture KumoScale™ architecture

Functions (Modules)

1. KumoScale™ Storage Node
Storage Server that runs KumoScale™ Software

2. Data Path
Network data path to connect between server application and storage via NVMe-oF

3. Control Path
Network control path to manage internal data services provided by KumoScale.

4. Provisioner Service
Carve out appropriate storage capacity and provision preferred QoS from storage node by predefined parameters.

5. CSI Driver
Container Storage Interface drive for KumoScale. Tightly coupled with CSI driver.

6. Telemetry Database
Database to store variety of statistics information in server and KumoScale storage node.

Platform Requirements

KumoScale™software has been tested on both bare metal, OpenStack and Kubernetes® deployments on a wide range of industry standard servers. Any NVMe-oF™ compliant initiator can be used, including Linux® kernel version 4.8 or later. Supported platform is show below.

Components

Minimal Requirement

Memory

64GB DDR4

System Disk

2 x 128 GB SATA DOM

NIC
  • MCX516A-CCAT or MCX545A-CCAN ConnectX®-5 EN network interface card, 100GbE dual/single port QSFP28, PCIe® 3.0 x16 ROHS R6
  • MCX416A-CCAT ConnectX®-4 EN network interface card, 100GbE dual/single port QSFP28, PCIe® 3.0 x16 ROHS R6
  • Intel® 810
  • MCX516A-CCAT or MCX545A-CCAN ConnectX®-5 EN network interface card, 100GbE dual/single port QSFP28, PCIe® 3.0 x16 ROHS R6
  • MCX416A-CCAT ConnectX®-4 EN network interface card, 100GbE dual/single port QSFP28, PCIe® 3.0 x16 ROHS R6
  •  Intel® 810

Power Supply

Dual power supply, hot swappable

Management Interface

A dedicated management port is optional. KumoScale™ can use the data port for management traffic, or it can utilize a dedicated management port.

KumoScale™ Provisioner

KumoScale™ Provisioner does not require any additional servers nor a container.

V3.22 User Manual

Download V3.22 User Manual (Zip : 78.8MB) Download

The KumoScale V3.22 User Manual includes:

  • Hardware Compatibility List (HCL)
  • Which KumoScale Deployment Mode Should I Use?
  • Release Notes
  • Installation Guide for Appliance Mode
  • Installation Guide for Managed Mode with Kubernetes
  • NVMe™ Host Patch
  • User Guide
  • Cluster Manager CLI
  • Kubernetes™ CSI Driver Guide
  • Openstack™ User Guide
  • Provisioner REST API Guide
  • KumoScale Metric Collection
  • Grafana™ Dashboard Guide
  • Ansible™ User Guide

Documents

Product Brief (PDF : 1.5MB) PDF will open in a new window.

This document describes KumoScale™ software overview, feature and advantage as well as typical use case and environmental information for deployment.

Introducing Cross-Domain Data Replication in KumoScale™ Software (PDF : 810KB) PDF will open in a new window.

This document discusses the architecture and deployment of Cross Domain Data Replication that provides data protection for KumoScale. KumoScale CDDR implements protection and automatic self-healing mechanism when there is system issue.

KumoScale™ Software Improves Flash Performance at Data Center Scale compared to Ceph™ Software (PDF : 720KB) PDF will open in a new window.

This document discusses performance advantage of KumoScale™ software running as NVMe-oF™ target  comparing to Ceph that provides similar storage systems functionality in data center scale.

An Introduction to PCIe® 4.0 performance with KIOXIA CM6 Series SSDs and KumoScale™ Software (PDF : 5MB) PDF will open in a new window.

This document discusses performance testing result with KumoScale™ running as NVMe-oF™ target with RDMA transport on PCIe® Gen 4 server platform and CM6 SSD. The performance result includes single SSD performance as well as scalability by incresing number of SSDs.

[KIOXIA Case Study] How NVMe™ / NVMe-oF™ Technology Helps to Shorten Machine Learning and Deep Learning Workflow (PDF : 790KB) PDF will open in a new window.

KIOXIA is further developing more accurate reliability algorithms in addition to existing ECC technology for NAND memory devices.This document discusses KIOXIA internal use case of KumoScale™ Softwware that runs fast block storage for machine learning and deep learning processing for this purpose.

GPUDirect Storage Perfromance Report and NVMe-oF™ Contribution (PDF : 3.6MB) PDF will open in a new window.

Fast block storage is more and more important for AI/ML processing. This document discusses the testing result of the combination with NVIDIA GPUDirect storage and NVMe™ storage by KumoScale™ software , and how this combination reduces processing time for entire workflow.

Inquiries

Please contact us from Inquiry form.

  • Please agree to the Important Considerations before Making an Inquiry and select KumoScale in the "Products" in the inquiry form to contact us.
Inquiry form

Press Release

Press Release regarding KumoScale™
  • Contained information, such as price, specification, services, and contact, is as of announcement date.
  • : 15us latency addition at 4KB read compared to DAS. Measured by KIOXIA in June 2020 using measurement tool specified by KIOXIA. 15us is the difference of 4KB read latency between DAS and NVMe-oF™ storage configuration on the same hardware.
  • NVMe and NVMe-oF are registered or unregistered marks of NVM Express, Inc. in the United States and other countries.
  • PCIe is a registered trademark of PCI-SIG.
  • Kubernetes is a registered trademark of The Linux Foundation in the United States and/or other countries.
  • Ansible is a registered trademark of Red Hat, Inc. in the United States and other countries.
  • Linux is a registered trademark of Linus Torvalds in the U.S. and other countries.
  • The OpenStack Word Mark is a registered trademark of the OpenStack Foundation, in the United States and other countries and are used with the OpenStack Foundation's permission. We are not affiliated with, endorsed or sponsored by the OpenStack Foundation, or the OpenStack community.
  • Prometheus is a registered trademark of The Linux Foundation.
  • Grafana and Loki are trademarks or registered trademarks of Grafana Labs, Inc.
  • Intel is a trademark of Intel Corporation or its subsidiaries.
  • All other company names, product names, and service names mentioned herein may be trademarks of their respective companies.
