Enterprise SSD
Enterprise SSDs are suitable for high-performance Tier 0 computing, server and storage systems that require high levels of performance and reliability.
KIOXIA Enterprise SSDs equip the flash memory and controller developed by KIOXIA and offer high reliability, data protection incorporating power-loss-protection (PLP) and encryption technology to support enterprise environments and applications. Light weight and low power consumption will make the systems more energy efficient.
Enterprise SSD Lineup
Data Sheet
Product Category
|
SCM SSD |
Low-latency yet cost-effective high-capacity enterprise-class solid-state storage ideal for enterprise and large data center applications, such as server caching and write logging. Applicable Products |
|---|---|
|
Read Intensive SSD |
High performance enterprise-class solid-state storage suitable for cost sensitive and read intensive applications characterized by infrequent write operations or predominantly large block & sequential data pattern workloads. Applicable Products |
|
Mixed Use SSD |
High performance enterprise-class solid-state storage developed with a balance of cost, performance and endurance for write and read mixed applications, such as media streaming, data warehousing and web servers. Applicable Products |
|
Write Intensive SSD |
High performance enterprise-class solid-state storage providing high levels of performance and endurance for a wide range of write intensive applications, from Big Data Analytics, HPC (High Performance Computing) to mainstream server and storage systems. Applicable Products |
FL Series
The FL6 series is a dual-port PCIe® 4.0 / NVMe™ SSD utilizing low latency, high endurance KIOXIA XL-FLASH Storage Class Memory (SCM). It provides fast system response for latency-sensitive applications, such as server caching, write logging, and read / write cache for tiered storage in enterprises and hyperscale data centers.
* Table can be scrolled horizontally.
|
FL6 Series (2.5-inch)
|
|
|---|---|
|
Product Category |
Enterprise SCM SSD |
|
Key Applications |
|
|
DWPD |
60 |
|
Interface |
PCIe® 4.0, NVMe™ 1.4 |
|
Maximum Interface Speed |
64 GT/s (Gen4 single x4, dual x2) |
|
Flash Memory Type |
|
|
Storage Capacity (GB) |
3,200 / 1,600 / 800 |
|
Security Option |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
Documents
CM Series
The CM Series are dual-port PCIe® / NVMe™ SSDs supporting capacities up to 30.72TB, and available in a 2.5-inch form factor and in an E3.S form factor. These SSDs feature Power Loss Protection (PLP) and offer a range of security/encryption options.
CM7 Series
* Table can be scrolled horizontally.
|
CM7-V Series (2.5-inch)
|
CM7-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Enterprise Mixed Use SSD |
Enterprise Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
For U.2 host: 128 GT/s (PCIe® Gen5 single x4, dual x2) |
For U.2 host: 128 GT/s (PCIe® Gen5 single x4, dual x2) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 |
30,720 / 15,360 / 7,680 / 3,840 / 1,920 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
2.5-inch |
* Table can be scrolled horizontally.
|
CM7-V Series (E3.S)
|
CM7-R Series (E3.S)
|
|
|---|---|---|
|
Product Category |
Enterprise Mixed Use SSD |
Enterprise Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
128 GT/s (PCIe® Gen5 single x4, dual x2) |
128 GT/s (PCIe® Gen5 single x4, dual x2) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 |
15,360 / 7,680 / 3,840 / 1,920 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
E3.S |
E3.S |
* Table can be scrolled horizontally.
|
CM7-V Series (2.5-inch)
|
CM7-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Enterprise Mixed Use SSD |
Enterprise Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
64 GT/s (PCIe® Gen4 single x4, dual x2) |
64 GT/s (PCIe® Gen4 single x4, dual x2) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 |
30,720 / 15,360 / 7,680 / 3,840 / 1,920 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
2.5-inch |
Documents
CM6 Series
* Table can be scrolled horizontally.
|
CM6-V Series (2.5-inch)
|
CM6-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Enterprise Mixed Use SSD |
Enterprise Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 4.0, NVMe™ 1.4 |
PCIe® 4.0, NVMe™ 1.4 |
|
Maximum Interface Speed |
64 GT/s (Gen4 single x4, dual x2) |
64 GT/s (Gen4 single x4, dual x2) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 / 800 |
30,720 / 15,360 / 7,680 / 3,840 / 1,920 / 960 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
2.5-inch |
Documents
PM Series
The PM Series of dual-port 24G SAS SSDs are available in a 2.5-inch (15mm thickness) form factor with capacities up to 30.72 TB. These SSDs feature Power Loss Protection (PLP) and offer a range of security/encryption options.
PM7 Series
* Table can be scrolled horizontally.
|
PM7-V Series (2.5-inch)
|
PM7-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Enterprise Mixed Use SSD |
Enterprise Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
SAS-4, 22.5 Gbit/s |
SAS-4, 22.5 Gbit/s |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 |
30,720 / 15,360 / 7,680 / 3,840 / 1,920 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
2.5-inch |
Documents
PM6 Series
* Table can be scrolled horizontally.
|
PM6-M Series (2.5-inch)
|
PM6-V Series (2.5-inch)
|
PM6-R Series (2.5-inch)
|
|
|---|---|---|---|
|
Product Category |
Enterprise Write Intensive SSD |
Enterprise Mixed Use SSD |
Enterprise Read Intensive SSD |
|
Key Applications |
|
|
|
|
DWPD |
10 |
3 |
1 |
|
Interface |
SAS-4, 22.5 Gbit/s |
SAS-4, 22.5 Gbit/s |
SAS-4, 22.5 Gbit/s |
|
Flash Memory Type |
|
|
|
|
Storage Capacity (GB) |
3,200 / 1,600 / 800 / 400 |
12,800 / 6,400 / 3,200 / 1,600 / 800 |
30,720 / 15,360 / 7,680 / 3,840 / 1,920 / 960 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
2.5-inch |
2.5-inch |
Documents
Products by Applications
The enterprise data center needs non-stop storage with high levels of performance and reliability. It requires continuous innovations to keep applications running effectively and efficiently, delivering more value with each generation of SAS and NVMe™ technologies.
Support
You can download past product information, white papers, and data sheets, etc.
Please contact us if you have any technical questions, requests for materials, are interested in samples or purchases of business products (Memory, SSD), etc.
Get warranty and support information about SSD Products.
- Definition of capacity: KIOXIA Corporation defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the definition of 1GB = 230 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media files) will vary based on file size, formatting, settings, software and operating system, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
- DWPD: Drive Write Per Day. One full drive write per day means the drive can be written and re-written to full capacity once a day every day for five years, the stated product warranty period. Actual results may vary due to system configuration, usage and other factors.
- Read and write speed may vary depending on the host device, read and write conditions, and file size.
- PCIe is a registered trademark of PCI-SIG.
- NVM Express is a registered or unregistered mark of NVM Express, Inc. in the United States and other countries.
- All other company names, product names, and service names mentioned herein may be trademarks of their respective companies.
KIOXIA has developed many “world-first” technologies, such as NAND flash memory and created innovation. As a leading company in “memory,” KIOXIA will continue to work on cutting-edge research and development to create innovation.
