Data Center SSD
KIOXIA Data Center SSDs which are equipped with flash memory, firmware and a controller developed by KIOXIA are suitable for cloud-based applications run in an industry standard server environment to be scaled out in a cloud.
These SSDs include data protection with power-loss protection (PLP) and encryption technology options to increase safety and security.
Data Center SSD Lineup
Data Sheet
Product Category
|
Data Center Read Intensive SSD |
Data center-class solid-state storage suitable for cost sensitive and read intensive applications characterized by infrequent write operations or predominantly large block & sequential data pattern workloads. Applicable Products |
|---|---|
|
Data Center Mixed Use SSD |
Data center-class solid-state storage developed with a balance of cost, performance and endurance for write and read mixed applications, such as media streaming, data warehousing and web servers. Applicable Products |
CD Series
The CD Series are PCIe® / NVMe™ SSDs suitable for scale-out and cloud applications, available in a 2.5-inch form factor (a capacity lineup of up to 30.72 TB) and in an E3.S form factor (a capacity lineup of up to 15.36 TB).
CD8P Series
* Table can be scrolled horizontally.
|
CD8P-V Series (2.5-inch)
|
CD8P-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Data Center Mixed Use SSD |
Data Center Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
128 GT/s (PCIe® Gen5 x4) |
128 GT/s (PCIe® Gen5 x4) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 |
30,720 / 15,360 / 7,680 / 3,840 / 1,920 |
|
Security Option |
SIE, SED |
SIE, SED |
|
Form Factor |
2.5-inch |
2.5-inch |
* Table can be scrolled horizontally.
|
CD8P-V Series (E3.S)
|
CD8P-R Series (E3.S)
|
|
|---|---|---|
|
Product Category |
Data Center Mixed Use SSD |
Data Center Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
128 GT/s (PCIe® Gen5 x4) |
128 GT/s (PCIe® Gen5 x4) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 |
15,360 / 7,680 / 3,840 / 1,920 |
|
Security Option |
SIE, SED |
SIE, SED |
|
Form Factor |
E3.S |
E3.S |
CD8 Series
* Table can be scrolled horizontally.
|
CD8-V Series (2.5-inch)
|
CD8-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Data Center Mixed Use SSD |
Data Center Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 4.0, NVMe™ 1.4 |
PCIe® 4.0, NVMe™ 1.4 |
|
Maximum Interface Speed |
64 GT/s (PCIe® Gen4 x4) |
64 GT/s (PCIe® Gen4 x4) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 / 800 |
15,360 / 7,680 / 3,840 / 1,920 / 960 |
|
Security Option |
SIE, SED |
SIE, SED |
|
Form Factor |
2.5-inch |
2.5-inch |
CD8/CD8P Documents
CD7 Series
* Table can be scrolled horizontally.
|
CD7-V Series (2.5-inch)
|
CD7-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Data Center Mixed Use SSD |
Data Center Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 4.0, NVMe™ 1.4 |
PCIe® 4.0, NVMe™ 1.4 |
|
Maximum Interface Speed |
64 GT/s (PCIe® Gen4 x4) |
64 GT/s (PCIe® Gen4 x4) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 / 800 |
15,360 / 7,680 / 3,840 / 1,920 / 960 |
|
Security Option |
ー |
SIE |
|
Form Factor |
2.5-inch |
2.5-inch |
CD6 Series
* Table can be scrolled horizontally.
|
CD6-V Series (2.5-inch)
|
CD6-R Series (2.5-inch)
|
|
|---|---|---|
|
Product Category |
Data Center Mixed Use SSD |
Data Center Read Intensive SSD |
|
Key Applications |
|
|
|
DWPD |
3 |
1 |
|
Interface |
PCIe® 4.0, NVMe™ 1.4 |
PCIe® 4.0, NVMe™ 1.4 |
|
Maximum Interface Speed |
64 GT/s (PCIe® Gen4 x4) |
64 GT/s (PCIe® Gen4 x4) |
|
Flash Memory Type |
|
|
|
Storage Capacity (GB) |
12,800 / 6,400 / 3,200 / 1,600 / 800 |
15,360 / 7,680 / 3,840 / 1,920 / 960 |
|
Security Option |
SIE, SED, FIPS SED |
SIE, SED, FIPS SED |
|
Form Factor |
2.5-inch |
2.5-inch |
CD6 Documents
XD Series
KIOXIA XD Series E1.S SSDs are designed to the Enterprise and Datacenter Standard Form Factor (EDSFF) E1.S specification to address the specific requirements of hyperscale applications, including the performance, power and thermal requirements of the Open Compute Project (OCP) Datacenter NVMe™ SSD Specification.
XD8 Series
* Table can be scrolled horizontally.
|
XD8 Series (E1.S)
|
|
|---|---|
|
Key Applications |
|
|
DWPD |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
128 GT/s (PCIe® Gen5 x4) |
|
Flash Memory Type |
|
|
Storage Capacity (GB) |
7,680 / 3,840 / 1,920 |
|
Security Option |
SED |
|
Form Factor |
E1.S (9.5 mm, 15 mm) |
XD7P Series
* Table can be scrolled horizontally.
|
XD7P Series (E1.S)
|
|
|---|---|
|
Key Applications |
|
|
DWPD |
1 |
|
Interface |
PCIe® 5.0, NVMe™ 2.0 |
|
Maximum Interface Speed |
64 GT/s (PCIe® Gen4 x4) |
|
Flash Memory Type |
|
|
Storage Capacity (GB) |
7,680 / 3,840 / 1,920 |
|
Security Option |
SED |
|
Form Factor |
E1.S (9.5 mm, 15 mm) |
XD8/XD7P Documents
Products by Applications
Data center class SSDs help cloud and hyperscale deployments provide storage that delivers consistent performance with predictable response times. Built on PCIe® and NVMe™ technology, data center SSDs are adjusted for a balance of performance, power and latency, applicable for scale-out and single server environments.
Support
You can download past product information, white papers, and data sheets, etc.
Please contact us if you have any technical questions, requests for materials, are interested in samples or purchases of business products (Memory, SSD), etc.
Get warranty and support information about SSD Products.
- Definition of capacity: KIOXIA Corporation defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the definition of 1GB = 230 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media files) will vary based on file size, formatting, settings, software and operating system, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
- DWPD: Drive Write Per Day. One full drive write per day means the drive can be written and re-written to full capacity once a day every day for five years, the stated product warranty period. Actual results may vary due to system configuration, usage and other factors.
- Read and write speed may vary depending on the host device, read and write conditions, and file size.
- PCIe is a registered trademark of PCI-SIG.
- NVM Express is a registered or unregistered mark of NVM Express, Inc. in the United States and other countries.
- All other company names, product names, and service names mentioned herein may be trademarks of their respective companies.
