EDSFF E3 Form Factor

E3 - Enterprise Servers and Storage

E3.S and E3.L size and dimension E3.S and E3.L size and dimension
Type Thickness (mm) Width (mm) Length (mm) Max Power (W)
E3.S 7.5 76 112.75 25
E3.S 2T 16.8 40
E3.L 7.5 142.2
E3.L 2T 16.8 70

PCIe® Lanes per Connector

4, 8, 16, 16+ PCIe lanes per connector diagram

E3 Max Power

E3 SSD rendering with max power values

Engineering Specifications from SNIA

E3 Mechanical/Electrical Specification SFF-TA-1008 A new window will open.
E3 Thermal Characterization Specification SFF-TA-1023 A new window will open.
EDSFF Connector Specification SFF-TA-1002 A new window will open.
EDSFF Connector Pinout (PCIe) SFF-TA-1009 A new window will open.

KIOXIA EDSFF E3 Offerings

KIOXIA CD8P Series

KIOXIA CD8P E3.S SSD product image

KIOXIA CD7 Series

KIOXIA CD7 E3.S SSD product image

KIOXIA CM7 Series

KIOXIA CM7 E3.S SSD product image
KIOXIA SSD Series Form Factor Endurance Interface Storage Capacity
(GB)		 Sequential Read/Write
(MB/s)		 Random Read/Write
(IOPS)
CD8P-V
 EDSFF E3.S Mixed Use
(3 DWPD for 5 years)		 PCIe® Gen5 x4, NVMe™ 2.0 1,600
3,200
6,400
12,800		 Up to
12,000 / 5,500
 Up to
2,000K / 400K
CD8P-R
 Read Intensive
(1 DWPD for 5 years)		 1,920
3,840
7,680
15,360		 Up to
2,000K / 200K
CD7-R
 Read Intensive
(1 DWPD for 5 years)
Designed to PCIe® Gen5 x4, NVMe™ 1.4		 1,920
3,840
7,680		 Up to
6,450 / 5,600		 Up to
1,050K / 180K
CM7-V
 Mixed Use
(3 DWPD for 5 years)

PCIe® Gen5 single x4, dual x2,

NVMe™ 2.0

 1,600
3,200
6,400
12,800		 Up to
14,000 / 7,000		 Up to
2,700K / 600K
CM7-R
 Read Intensive
(1 DWPD for 5 years)		 1,920
3,840
7,680
15,360		 Up to
2,700K / 310K

Companies Offering EDSFF E3.S-enabled Platforms

While E3 form factors began with a focus on traditional enterprise server and storage use cases, hyperscalers are evaluating E3 for use in scale-out environments. Many server, storage and SSD companies with 2.5-inch storage solutions are aligned with the E3 Family. Initial development and demonstration systems in support of the E3 Family of form factors are well underway with early full function development vehicles as shown.

Dell PowerEdge™ Servers A new window will open.
KIOXIA SSDs in ProLiant Servers A new window will open.
Supermicro® Servers A new window will open.

Learn and Evaluate

Press Releases

KIOXIA CD8P Series PCIe 5.0 NVMe Data Center SSD Named ‘Best of Show’ at Flash Memory Summit 2023
KIOXIA Introduces New PCIe 5.0 SSDs for Enterprise and Data Center Infrastructures
KIOXIA First to Launch Data Center NVMe E3.S SSDs on Hewlett Packard Enterprise Systems
KIOXIA Introduces New Levels of Performance with Enterprise NVMe SSD Family Designed with PCIe® 5.0 Technology
KIOXIA Introduces Industry’s First EDSFF Solid State Drives Designed with PCIe® 5.0 Technology
  • Product image may represent a design model.
  • PCIe is a registered trademark of PCI-SIG.
  • NVMe is a registered or unregistered mark of NVM Express, Inc. in the United States and other countries.
  • Other company names, product names, and service names may be trademarks of third-party companies.
  • All rights reserved. Information, including product specifications, content of services, and contact information is believed to be accurate as of October, 2023, but is subject to change without prior notice. Technical and application information contained here is subject to the most recent applicable KIOXIA product specifications.
